美国UVP B-100AP高强度100瓦长波紫外线灯95-0127-02，实验室荧光分析检验用
B-100系列强紫外灯为100W长波紫外线灯，外壳由有Cool-Touch阻热材料制造，长时间工作不产生高温。
B-100AP强紫外线灯-100瓦365nm紫外灯，可以应用在汽车行业中，用来检测设计漏洞，在线路搭乘制造，矿物学研究等也有应用。
介绍：美国UVP公司被德国Analytik Jena AG公司收购

主要
• 功率为100W，（除B-100SP）
• 在380mm处紫外线强度为5,000uW/cm2
• 灯泡的寿命1000至5000小时。
• 灯头连接到镇流器（除B-100SP）允许灯头360°旋转
• 在457mm距离处，可产生大约直径127mm的紫外光斑

B-100系列灯有多种型号选择
所有“P”系列灯都具有Cool-Touch阻热材料外壳，没有高温产生，长时间灯头温度可以手持，可以面朝下放置在工作台也不会损坏。非“P”系列的是铝合金外壳。

B-100AP/B-100AP/R
B-100AP为100瓦长波紫外线灯，Cool-Touch阻热外壳。在457mm距离处，可产生大约直径127mm的强紫外光斑，灯头可旋转360度，2.4米的电源线。为增加流动性，可选择B-100AP/R包括6.1米长的电源线。B-100AP被应用在无损检测和荧光检测。

B-100A和A-100AR
B-100A为100W的长波紫外线灯，B-100A防刮铝合金外壳，2.4米电源线。为了增加流动性，选择B-100AR包括6.1米长的电源线。应用非破坏性测试和荧光检测。

型号

选件

美国UVP公司B-100AP高强度紫外线灯

应用：在汽车行业中，用来检测泄漏，荧光探伤等。

在实验室应用：用来光聚合，催化，生物聚合，矿物学研究等。

外壳由Cool-Touch阻热材料制造，可以长时间使用而不产生高温。

B-100系列高强度紫外灯的型号选择：

其中美国UVP B-100AP高强度紫外灯的参数Main Features：
紫外线波长：365nm（UV-A）
紫外线光强度：5000uw/cm2，50W/m2
灯泡功率：100瓦（100W）
灯泡平均使用寿命：约使用3000小时
灯泡类型：高压汞灯

•The B-100 Series lamps are available in a variety of styles: All "P" series lamps come with the special heat-resistant plastic Cool-TouchTM housing which allows users to handle the lamp head regardless of how long the lamp has been operating. These rugged lamps can be placed face down on a working surface without damage to the filter. The non "P" models are built with an aluminum lamp head.
•A 100 watt spot bulb is standard with all models (except the B-100SP); the bulb is rated at 5000 hours.
•Self-ballasted bulb included with the B-100SP has an average life of 450 to 2000 hours depending on use patterns
•The lamp head connects to the transformer base for hands free use (all models except B-100SP) allowing the lamp head to rotate a full 360°; remove the lamp from the base for additional mobility

B-100AP高强度紫外灯的应用Applications
Fluorescence Inspections
Non Destructive Testing
Leak Detection
Readmission
UV Applications Notes
UV Application List

B-100AP and B-100AP/R
B-100AP models feature 100 watt longwave UV, Cool-Touch housing and ballast base. At 18 in. (457 mm), the lamp produces a highly intense center of UV irradiance about 5 in. (127 mm) in diameter. Lamp head can rotate 360 degrees when attached to the base for hands-free operation or lamp can be removed from the base. 8 ft primary and secondary cords. For added mobility, select the B-100AP/R which includes 20 ft (6.1m) primary and secondary cords. Uses for these lamps include non-destructive testing and fluorescence inspection.

B-100A and A-100AR
The longwave B-100A is manufactured with a scratch-resistant aluminum housing which connects to ballast base with an 8 foot cord; 8 foot secondary cord is included. The 100 watt longwave UV bulb is excellent for inspection applications. For increased mobility, select the B-100AR which includes 20 ft (6.1m) primary and secondary cords. Uses for these lamps include non-destructive testing and fluorescence inspection.

B-100SP
This 160 watt longwave, self-ballasted lamp is a highly portable, high intensity lamp for automotive leak detection applications. The ballast is built directly into the bulb. The B-100SP features the Cool-Touch housing and an 8 ft. (2.44m) cord.

美国UVP B-100Y表面检测灯，B-100Y and B-100YP
These models feature a yellow filter which blocks wavelengths shorter than 500nm and produces three strong mercury lines at 543, 574 and 576nm. The high contrast light is produced for fine surface particle detection. Particles down to 10 microns are routinely visible with this lamp. B-100Y is built with the aluminum housing; B-100YP with a plastic housing. These lamps are excellent for semiconductor wafer inspection as most photoresist absorption occurs below 450nm
